How to Fix Common Skin and Hair Issues Using Texture Grafting

From a retouching standpoint, there are few things more unpleasant or challenging than dealing with chunks of hair on the face, missing patches of skin texture and large folds of skin. Generally the existing tools in photoshop such as the healing brush or patch tool fail in these situations and we often end up with unnatural or unpolished results. When all else fails I often turn to a technique called texture grafting to deal with a multitude of issues.

What the Heck is Texture Grafting?

The idea behind texture grafting is to utilize the power of frequency separation and tackle a problem by gradually replacing texture and then blending tones and brightness to recreate a realistic appearance. Now this is a more advanced technique and involves four stages:

  • Step 1: Separate the image into high and low frequencies with frequency separation
  • Step 2: Replace areas of missing or undesirable texture with areas of good texture
  • Step 3: Blend the underlying tones
  • Step 4: Add polish with dodging and burning

For the sake of brevity I assume you're already familiar with frequency separation as well as the basics of the dodge and burn technique. If you're not, click on the corresponding links to the topics mentioned above for an in depth explanations on both. I also recommend reading my article on the Keys to a Great Retouch for a lot of the retouching foundation theory you should understand. While all this may seem complicated, by breaking down a problem into stages it actually becomes quite simple and intuitive at each stage. Steps 2-4 deal with issues as follows:

  • At step 2, fix texture issues and ignore the underlying color and brightness
  • At step 3, blend the colors and get brightness somewhat close
  • At step 4, take care of any remaining brightness issues by shaping the area and making everything flow together

In the corresponding video I demonstrate tackling the two problem areas shown in the image below from start to finish to give you an idea of how the technique can be applied. Once you master the process, you'll see that it can be used for a variety of scenarios which are discussed below. As with anything it does require a bit of practice before you get things looking perfect.

Fstoppers-Michael-Woloszynowicz-Texture-Grafting-Common-Scenarios

Other Uses

One of the easiest problems to fix using this technique is that of missing or inconsistent texture on the cheekbones, nose or forehead (as shown in the animated gif below). Be creative with your selection of source texture such as grabbing texture from the other side of the face and flipping it, or by doubling up existing texture to multiply its intensity. Be sure to sample areas of similar texture as different areas of the face will have different texture depending on a number of factors. Take a look at my detailed discussion on texture in this article.

Fstoppers-Michael-Woloszynowicz-Texture-Grafting-Texture-Fill

Another approach is to fixing challenging areas by grafting texture from a completely different image. In the below example, I took the texture of the jawline (covered by hair) from another image and applied it to my destination image and blended the tones. The source image was shot at a slightly different angle and the tones didn't quite match up, but the texture was similar. Using the free transform tool to fit the texture into place and a bit of painting, I was able to deal with this tricky area in just a few minutes. If the image was shot relatively straight on, you can also grab the texture from the other side of the face, flip it and then blend the tones accordingly.

Fstoppers-Michael-Woloszynowicz-Texture-Grafting-Common-Alt-Example

Finally, we can deal with issues within the hair itself as I've done in the image below. Here I took the texture of the straight hair, free transformed it, and covered the crossing hairs and blended the underlying luminosity (since it's B&W we have no color to deal with) using the same process described in the video. Be prepared for multiple iterations for problems like this, and given that it's one of the most difficult cases, I recommend practicing on some of the simpler situations described above before tackling it.

Fstoppers-Michael-Woloszynowicz-Texture-Grafting-Common-Hair-Graft-Example

Once you begin to see the image as two separate frequencies you'll be amazed at how much you can do by extending the common frequency separation approach into the workflow described in the video. It's not something you'll have to do in every image but when you've exhausted all your other options, texture grafting can come to the rescue and produce clean and natural results.
